HEAVY DUTY STRUCTURAL
•
CORE-FILLED CONCRETE BLOCK
Concrete Block Core-Filled Retaining Wall
Complete construction of a structural Over 20-meter long by 1-meter high core-filled concrete block retaining wall. Includes steel reinforced concrete footing, rear liquid waterproofing, dimple sheet protection, and ag-pipe drainage.
FULL SCOPE OF WORK (20m x 1m HIGH SCOPE)
- Footing & Trench: Excavation and 400mm x 300mm concrete footing with steel rebar.
- Blockwork & Core Fill: 200 series Besser blocks with N12 steel bars, 100% concrete core-filled.
- Waterproofing: 2-coat liquid membrane behind wall with dimple sheet drain.
- Drainage System: 100mm slotted ag-pipe in blue metal gravel filter envelope.
FULL RETAINING WALL PACKAGE COST
$23,600.00 ($680/m)
$21,600.00 ($580/m)
SAVE 15% SPECIAL
+GST INCLUDED AT CHECKOUT
Important Terms: Includes trenching, rebar steel, concrete fill, membrane, and gravel backfill. Excludes: Rock excavation machinery fees & council engineering plans if required over 1m height. *Site assessment required. T&Cs apply.
This reference case study serves as an indicative benchmark for core-filled structural masonry walls on standard residential terrain.
